Removing the 3.5-inch hard drive
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
Remove the right-side cover.
Procedure
1 Lay the computer on the left side and disconnect the power cable from the hard
drive.
2 Disconnect the data cable from the hard drive.
3 Remove two screws (6-32UNCx3.6) that secure the hard-drive assembly to the
side-chassis.
59
