Replacing the processor-cooling
assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the four captive screws on the processor-cooling assembly with the slot
on the system board.
2 In sequential order (as indicated on the processor-cooling assembly), tighten the
captive screws that secure the processor-cooling assembly to the system board.
3 Align the tabs on the fan with the slots on the chassis and place the fan in
position.
4 Replace the screw (6-32UNCx3.6) that secures the fan to the chassis.
5 Connect the processor-cooling assembly cable to the system board.
6 Place the computer in an upright position.
7 Connect the fan cable to the system board.
8 Place the computer in an upright position.
Post-requisites
Replace the right-side cover.
