Removing the front bezel
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Prerequisites
1 Remove the right-side cover.
2 Remove the front cover.
3 Remove the slim optical drive.
4 Remove the front I/O panel.
5 Remove the logo board.
6 Remove the front-panel light board.
7 Remove the light bar.
8 Remove the top cover.
Procedure
1 Place the computer in the standing position and remove the 11 screws (M3x5)
that secure the front bezel to the chassis.
96
