Replacing the front I/O-panel
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Slide the front I/O panel into the front I/O panel bay through the front of the
computer.
2 Replace the two screws (M3x5) that secures the front I/O panel to the chassis.
3 Connect the front-audio cable, USB 2.0 cable, USB 3.0 cable and USB 3.1 (Type-
C) cable to the system board.
4 Place the computer in an upright position.
Post-requisites
1 Replace the front cover.
2 Replace the right-side cover.
