Replacing the top cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at
www.dell.com/
regulatory_compliance.
Procedure
1 Align the tabs on the top cover with the slots on the chassis.
2 Slide the top cover towards the front of the chassis and secure the top cover in
place.
3 Replace the screw (M3x5) that secures the top cover to the chassis.
4 Place the computer in an upright position.
Post-requisites
Replace the right-side cover.
95
