Figure 78. Installing an OCP card
Next steps
1. Install the expansion card riser 2.
2. Install the expansion card riser 1.
3. Follow the procedure listed in After working inside your system.
Removing an OCP card
Prerequisites
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedure listed in Before working inside your system.
3. Remove the expansion card riser 1.
4. Remove the expansion card riser 2.
Steps
1. Lift the OCP card retention latch.
2. Disengage the OCP card and remove it from the sled.
NOTE:
Install an expansion card filler bracket over an empty expansion slot to maintain Federal Communications
Commission (FCC) certification of the system. The brackets also keep dust and dirt out of the system and aid in proper
cooling and airflow inside the system.
Installing and removing system components 71
