Figure 23. Installing the expansion card riser 1
Next steps
1. Follow the procedure listed in After working inside your system.
Removing the expansion card riser 2
Prerequisites
NOTE:
Install an expansion card filler bracket over an empty expansion slot to maintain Federal Communications
Commission (FCC) certification of the system. The brackets also keep dust and dirt out of the system and aid in proper
cooling and airflow inside the system.
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedure listed in Before working inside your system.
3. Remove the expansion card riser 1.
Steps
1. If applicable, disconnect the MB_SL1 and MB_SL2 connector.
a. To remove the MB_SL1 and MB_SL2 connector, hold and pull the blue pull tab.
2. Using Phillips #1 screw driver, remove the screws that secure the expansion card riser 2.
3. Holding the blue touch point, remove the expansion card riser from the chassis.
Installing and removing system components
33
