4.3 RAID 50 drive layouts and total reported usable storage
Table 13 shows the drive layouts that are enforced when using a RAID 50 policy based on the number
of drives in each array/hot spare configuration and the total usable storage available for each model.
RAID 50 (RAID 5 sets in a striped set) is created by first creating two or more RAID 5 sets and then
striping data over those RAID5 sets. RAID 50 implementations can tolerate a single drive failure per
RAID5 set.
Table 13 RAID 50 drive layouts and total reported usable storage available with hot spares (in GB)
Disk drives Hot spare No hot spare
6
5 Data/Parity + 1 Hot-spare
N/A
(a)
7
6 Data/Parity + 1 Hot-spare
N/A
(a)
8
6 Data/Parity + 2 Hot-spares
8 data/parity
12
(d)
10 Data/Parity + 2 Hot-spares
12 data/parity
14
12 Data/Parity + 2 Hot-spares
14 data/parity
16
14 Data/Parity + 2 Hot-spares
16 data/parity
24
(d)
22 Data/Parity + 2 Hot-spares
24 data/parity
48
(b)
46 Data/Parity + 2 Hot-spares
N/A
(c)
(a) RAID 50 requires an even number of disk drives. A 7 drive configuration without hot-spare would result in odd
number of disk drives.
(b) 48 drive arrays implement stripes across multiple RAID 5 sets within a single chassis.
(c) 48 drive arrays cannot implement a no hot-spare policy.
(d) PS4100/PS6100 models only
Total reported usable storage when using hot spares: All models prior to PS4100/PS6100
Disk
Drive
Qty / Size
50
(a)
100
(a)
74 146 250 300 400 450 500 600 750 1000 2000 3000
7
(b)
- - - - 888 - - - - - - - - -
8
(c)
- - - - 888 - - - - - - - - -
14
(d)
- - 660 - 2224 - 3566 - 4460 - 6695 - - -
16
532 1066 - 1566 2671 3207 4280 4817 5353 6427 8037 10719 21819 32972
48
- - - - - - - - 18062 21677 - 36136 69260 107151
Total reported usable storage when using hot spares: PS41x0/PS61x0
Disk
Drive
Qty / Size
146 200
(e)
300 400
(e)
500 600 900 1000 2000 3000
6
- - - - 1781 2129 - 3563 7280 11008
12
1044 - 2129 2949 3563 4280 6430 7137 14571 21975
14
1304 - 2670 - 4459 5353 8036 8930 - -
24
2355 3328 4815 6666 8038 9646 14474 16087 32727 49455
(a) Solid State Disk
(b) Legacy PS50E
(c) PS4000E and PS6000E only
(d) Legacy PS70E,PS100E, PS100X, PS200E and PS300E
(e) PS6100S (SSD) only
