Dell Latitude C840 Service Manual

Hard Drive and Fixed Optical Drive: Dell Latitude C840 Service Manual
Fixed Optical Drive
NOTICE: Disconnect the computer and attached devices from the electrical outlet and remove
any installed batteries.
NOTICE: To avoid ESD, ground yourself by using a wrist grounding strap or by periodically
touching unpainted metal on the computer.
1 captive screw
2 pull tab
Removing the Fixed Optical Drive
1. Follow the instructions in "Preparing to Work Inside the Computer."
2. Loosen the captive screw on the bottom of the computer.
3. Turn the computer over (to keep the captive screw from interfering with the pull tab) and pull
out the pull tab.
file:///I|/SERVICE%20MANUALS/DELL%20MANUALS/LA...20ok/Latitude/C840/C840_SERVICE_MANUAL/hdd.htm (3 of 4)6/21/2004 1:36:11 AM
