Dell Latitude C840 Service Manual

Keyboard: Dell Latitude C840 Service Manual
2 keyboard
3 right side of computer
5. Lift the right end of the keyboard and slide it slightly toward the right side of the computer to
disengage the tabs at the left end.
6. Pivot the keyboard and balance it upright on the left side of the computer.
1 keyboard cable
2 keyboard interface connector
3 system board
7. Disconnect the keyboard cable and lay the keyboard aside.
Replacing the Keyboard
file:///I|/SERVICE%20MANUALS/DELL%20MANUALS/LA...Latitude/C840/C840_SERVICE_MANUAL/keyboard.htm (3 of 4)6/21/2004 1:36:14 AM
