Dell OptiPlex 5050 Small Form Factor User Manual

Memory modules
Removing memory module
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. Side Cover
b. Front bezel
3. Open the Front panel door.
4. To remove the memory module:
a. Pull the clips securing the memory module until the memory module pops up.
b. Lift the memory module from the connector on the system board.
Installing memory module
1. Align the notch on the memory module with the tab on the connector.
2. Insert the memory module into the connector.
3. Press the memory module until the memory module retention tabs click into place.
4. Close the front panel door.
5. Install the:
a. Front bezel
b. Side Cover
6. Follow the procedure in After working inside your computer.
Expansion card
Removing PCIe expansion card
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. Side Cover
b. Front bezel
3. Remove the Front panel door.
4. To remove the PCIe expansion card:
a. Pull the release latch to unlock the PCIe expansion card [1].
b. Push the release tab [2] and lift the PCIe expansion card out of the computer [3].
NOTE: The release tab is at the base of the expansion card.
Field service information 33
