AMD Ryzen APUs
This topic explains AMD's Ryzen series of APUs.
Ryzen APUs are series of APU (CPU+GPU) offered with Vega 8/11 graphics processors. Ryzen APUs are performance
enhancements over the predecessor Ryzen CPUs incorporating the GPU on same chip as CPU cores.
AMD PT B350
AMD B350
● Chipset is perfect for power-users who value flexibility and overclocking control, but don't need the maximum PCIe
bandwidth required by multi-GPU configurations.
● AMD Socket AM4 represents the company's new future-proof platform targeting the fastest DDR4 memory.
● With processor-direct SATA and USB connectivity, configurable for real-world flexibility, the new AM4 platform takes
advantage of the leading-edge features
Specification
Table 3. Specification
Specification Details
PCI Express Gen3 Graphics 1x16(AMD Ryzen™)1 x 8 (AMD A-Series and Ryzen APU) / 1 x
4 (AMD Athlon™)
USB 3.1 G2 + 3.1 G1 + 2.0 2+6+6
SATA + NVMe 4 + x2 NVMe (or 2 SATA 1 x4 NVMe on AMD Ryzen™
Processor).
SATA Express* (SATA & GPP PCIe G3*) 1
PCI Express® GP x6 Gen2 (plus x2 PCIe Gen3 when no x4 NVMe)
SATA RAID 0,1,10
Dual PCI Express® slots No
Over-clocking Unlocked
AMD Radeon R7 M450
Key Specifications
The following table contains the key specifications of the AMD Radeon R7 M450:
Table 4. Key Specifications
Specification AMD Radeon R7 M450
Product Line AMD
API Supported DirectX 12 , OpenCL 1.2 , OpenGL 4.3
Clock Speed 925 MHz
Bus Width 128-bit
Memory Clock Speed 1.125 GHz
56 Technology and components
