Dell OptiPlex 5050 Small Form Factor User Manual

Installing power switch
1. Insert the power switch into the slot from the front of the computer and press it until it clicks into place.
2. Align the cable with the pins on the connector and connect the cable.
3. Close the front panel door.
4. Install the:
a. Front bezel
b. Side Cover
5. Follow the procedure in After working inside your computer.
Speaker
Removing speaker
1. Follow the procedure in Before working inside your computer.
2. Remove the:
a. Side Cover
b. Front bezel
3. Open the front panel door.
4. To remove the speaker:
a. Disconnect the speaker cable from the connector on the system board [1].
Field service information
39
