NOTE: Please wait for 10 minutes between AC cycles (Power off and Power on cycles) for graceful shutdown to occur
when XR4000r and XR4000z chassis has XR4000w installed. This ensures graceful shutdown of underlying hardware and
software components in the system.
Before working inside your system
Prerequisites
Follow the safety guidelines listed in the Safety instructions.
Steps
If applicable, remove the system from the rack.
For more information, see the Rail Installation Guide relevant to your rail solutions at www.dell.com/poweredgemanuals.
After working inside your system
Prerequisites
Follow the safety guidelines listed in Safety instructions.
Steps
1. If applicable, install the system into the rack.
For more information, see the Rail Installation Guide relevant to your system at www.dell.com/poweredgemanuals.
2. Reconnect the peripherals and connect the system to the electrical outlet, and then power on the system.
Recommended tools
You may need any or combination of the following tools to perform the removal and installation procedures:
● Key to the bezel lock. The key is required only if your system includes a bezel.
● Phillips 1 screwdriver
● Phillips 2 screwdriver
● Torx T8 screwdriver
● Wrist grounding strap connected to the ground
● ESD mat
You need the following tools to assemble the cables for a DC power supply unit:
● AMP 90871-1 hand-crimping tool or equivalent
● Tyco Electronics 58433-3 or equivalent
● Wire-stripper pliers to remove insulation from size 10 AWG solid or stranded, insulated copper wire
NOTE: Use alpha wire part number 3080 or equivalent (65/30 stranding).
Optional front bezel
Removing the front bezel
Prerequisites
1. Follow the safety guidelines listed in the Safety instructions.
2. Keep the bezel key handy.
Installing and removing system components
25
