Dell PowerEdge XR4000r system
configurations and features
The PowerEdge XR4000r system is a 2U rackmount chassis that supports:
● Up to four XR4510c 1U single-width compute sleds or up to two XR4520c 2U single-width compute sled or up to two
XR4510c 1U, single -width and one XR4520c 2U, single-width compute sleds and an optional nano-server (witness sled
XR4000w) example vSAN.
● Up to two redundant AC or DC power supply units
Topics:
• System configurations - front view for PowerEdge XR4000r
• System configurations - rear view for PowerEdge XR4000r
• Power supply unit indicator codes
• Locating the Express Service Code and Service Tag
•
System information label
• Rail sizing and rack compatibility matrix
System configurations - front view for PowerEdge
XR4000r
Figure 1. Front view of chassis with four 1U sleds and an optional witness sled
Table 1. Features available on the front of the system
Item Ports, panels, and
slots
Icon Description
1 XR4510c 1U sled N/A XR4510c server for computing.
2 XR4000w witness sled N/A Optional witness server with Intel Atom processor.
3 Power supply 1 Indicates PSU 1.
4 Power supply 2
Indicates PSU 2.
5 Information tag N/A
Information tag which contains service tag information.
2
6 Dell PowerEdge XR4000r system configurations and features
