Denon AVR-1513 Service Manual

113
PARTS LIST OF P.C.B. UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe modelE1C : China model
FRONT PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC102 943239005300M OPAMPBA4560RF-E2 HVIBA4560RF
Q1001 943219006820S TR KTC1027Y CVTKTC1027YT
Q1003,1004 943214500020S T.R,2SC3052 CVT2SC3052
Q1005 00MHT600141B1 TR KTA1271Y HVTKTA1271YT
Q1006 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q1008 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q1009 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
Q1011 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q1012 943216500020S T.R,RT1N141C(10K-10K) CVTRT1N141C
D1001,1002 00D9630328409 DIODE,RECTIFIERS CVD1N4007ST
D1003 90M-HD302360R DIODE,ZENER,1/2W,6.8V CVDZJ6.8BT
D1004 00D9430087209 DIODE,ZENER,1/2W,24V CVDZJ24BT
D1005 90M-HD302450R DIODE,ZENER,1/2W,13V CVDZJ13BT
D1012 943176010090S L.E.D,(GREEN/RED5PI) CVDBLBJEGJ204L
RESISTORS GROUP
R1001 nsp RES,CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T
R1004 nsp RES,CARBON(1/5W,1.8ohm,J) CRD20TJ1R8T
R1005,1006 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R1007 00MGD05103160 RES,CARBON(1/5W,10Kohm,J) CRD20TJ103T
R1008,1009 00MNN05221610 RES,CHIP(1608/5%/220ohm) CRJ10DJ221T
R1010 00MNN05393610 RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T
R1012-1015 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1016,1017 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R1018,1019 00MNN05101610 RES,CHIP(1608/5%/100ohm) CRJ10DJ101T
R1020 00MNN05332610 RES,CHIP(1608/5%/3.3Kohm) CRJ10DJ332T
R1021 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1024 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R1025,1026 00MNN05393610 RES,CHIP(1608/5%/39Kohm) CRJ10DJ393T
R1030 00MNN05100610 RES,CHIP(1608/5%/10ohm) CRJ10DJ100T
R1041,1042 00MNN05122610 RES,CHIP(1608/5%/1.2Kohm) CRJ10DJ122T
R1043 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R1045,1046 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R1047,1048 00MNN05471610 RES,CHIP(1608/5%/470ohm) CRJ10DJ471T
R1049-1052 00MNN05104610 RES,CHIP(1608/5%/100Kohm) CRJ10DJ104T
R1053 00MNN05100610 RES,CHIP(1608/5%/10ohm) CRJ10DJ100T
R1055,1056 00MNN05470610 RES,CHIP(1608/5%/47ohm) CRJ10DJ470T
R1057 00MNN05471610 RES,CHIP(1608/5%/470ohm) CRJ10DJ471T
R1058,1059 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1060,1061 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R1065 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R1066 943124500040S RES,M-OXIDEFILM(1W/4.7ohm) CRG1SANJ4R7RT
R1067 00MNN05100610 RES,CHIP(1608/5%/10ohm) CRJ10DJ100T
R1068 nsp RES,CHIP(1608/5%/0ohm) CRJ10DJ0R0T
R1069 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1071 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1072 00MNN05152610 RES,CHIP(1608/5%/1.5Kohm) CRJ10DJ152T
R1073 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1074 00MNN05152610 RES,CHIP(1608/5%/1.5Kohm) CRJ10DJ152T
R1075 00MNN05272610 RES,CHIP(1608/5%/2.7Kohm) CRJ10DJ272T
R1076 00MNN05102610 RES,CHIP(1608/5%/1Kohm) CRJ10DJ102T
R1077 00MNN05152610 RES,CHIP(1608/5%/1.5Kohm) CRJ10DJ152T
R1078 00MNN05272610 RES,CHIP(1608/5%/2.7Kohm) CRJ10DJ272T

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
