Denon AVR-1513 Service Manual

123
DIGITAL PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC11 943236012460S I.C,HDMITransceiver(LQFP-144P) CVIADV7623BSTZ
IC14 943248101030S I.C, OSD Serial Flash(AVR1513) CVIANAM1661AV *
IC15 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133
IC16 nsp I.C,DC-DCCONVERTER(3A,QFNT&R-38P) CVIEX3AV
IC51 nsp I.C,HDMIBUFFER CVIAD8195ACPZ
IC60 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI
IC61 943235100520S I.C,INPUTWITH8CHVOLUME(52PLQFP) CVINJU72340AFH3 *
IC62-64 00D2631289900 EOLitemI.C,OPAMP(DUAL/LOWNOISE) CVIAZ4580MTR-E1
IC66,67 00D2630934900 ICBA4510F HVIBA4510F
IC68 943231010390S I.C,REGULATOR(+5V,T0220IS) CVIKIA7805BPI
IC69 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133
IC71 90M-HC109700R I.C,VIDEOS/W(JRC) CVINJM2595MTE1
IC74 00D2631099006 I.C,REGULATOR(-5V,T0220IS) CVIKIA7905PI
IC81 943245010410S I.C,DSP(CIRRUSLOGIC) CVICS497024CVZ
IC82 943248101040S I.C, DSP Serial Flash(AVR1513) CVIANAM1660AV *
IC83 943236101210S I.C,16MBSDRAM(TSOP-50P) CVIM12L16161A5TG2Q *
IC84 90M-HC110090R I.C,CODEC+DIR(CIRRUSLOGIC) HVICS42528-CQ
IC85 00D2623198902 I.C,QUAD2-CHANNELMUX(TSSOP-16) HVITC74VHC157FT
IC91 943243100850S I.C , MAIN MCU(AVR1513) CVIANAM1659AV *
IC92 943246010440S I.C,EEPROM(32Kbit)ST CVIM24C32WMN6TP
IC95 943239010400S I.C,REGULATOR(3.3V/TO-252) CVINJM2845DL133
IC96 943182100150S I.C,SYSTEMRESET(2.5V,SOT-25A) CVIPST8425NR *
Q101 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q102 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q103 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q104 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q105 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q106 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q500 943215500020S T.R,RT1P141C(10K-10K) CVTRT1P141C
Q501 943216500040S T.R,RT1N241C(22K-22K) CVTRT1N241C
Q610 943214500030S T.R,MUTE CVTINC2001AC1
Q612 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C
Q613 943216500050S T.R,RT1N441C(47K-47K) CVTRT1N441C
Q614 943215500030S T.R,RT1P441C(47K-47K) CVTRT1P441C
Q901 943214500020S T.R,2SC3052 CVT2SC3052
Q903,904 943214500020S T.R,2SC3052 CVT2SC3052
Q907 943214500020S T.R,2SC3052 CVT2SC3052
Q910 943214500020S T.R,2SC3052 CVT2SC3052
Q918 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q919 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q920 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
D155 963209003510S DIODE,RELIABLEESDPROTECTION CVDCDS3C05HDMI1
D601,602 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D605,606 00D9430196306 DIODE,ZENER,1/2W,7.5V CVDZJ7.5BT
D609-611 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
D612 90M-HD302380R DIODE,ZENER,1/2W,3.6V CVDZJ3.6BT
D903 943209001080S DIODE,CHIP,SWITCHING CVD1SS355T
RESISTORS GROUP
R101 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R102 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T
R103 nsp RES,CHIP(1005/5%/0ohm) CRJ06IJ0R0T
R104 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R106 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R107 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R108 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T
R109 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R111 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
R112 nsp RES,CHIP(1005/5%/1Kohm) CRJ06IJ102T
R113 nsp RES,CHIP(1005/5%/22Kohm) CRJ06IJ223T
R114 nsp RES,CHIP(1005/5%/47Kohm) CRJ06IJ473T
NOTE
:
When update Firmware, please
conrm a last version in SDI.
Use the service board after
updating it.
