Denon AVR-1513 Service Manual

87
PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
C1 nsp FRONT PCB UNIT ASS'Y E3 COP12423B 1 *
C1 nsp FRONT PCB UNIT ASS'Y E2 COP12423F 1 *
C1 nsp FRONT PCB UNIT ASS'Y E1C COP12423C 1 *
C1-1 - FRONT PCB
C1-2 - POWER KNOB PCB
C1-3 - HEADPHONE PCB
C1-4 - PORTABLE PCB
C1-5 - USB PCB
C1-6 - FOR HDMI FFC CABLE PCB
C2 nsp MAIN PCB UNIT ASS'Y E3 COP12425B 1 *
C2 nsp MAIN PCB UNIT ASS'Y E2 COP12425C 1 *
C2 nsp MAIN PCB UNIT ASS'Y E1C COP12425D 1 *
C2-1 - MAIN PCB
C2-2 - CABLE PCB
C2-3 - HDMI CABLE PCB
C2-4 - CARD CABLE FIX PCB
C2-5 - TUNER PCB
C3 943639100070D DIGITAL PCB UNIT ASS'Y E3 COP12426B 1 *
C3-1 - DIGITAL PCB UNIT ASS'Y
C3-2 - F-HDMI PCB
C4 nsp POWER PCB UNIT ASS'Y E3 COP12424B 1 *
C4 nsp POWER PCB UNIT ASS'Y E2 COP12424C 1 *
C4 nsp POWER PCB UNIT ASS'Y E1C COP12424D 1 *
C4-1 - POWER PCB
C4-2 - REGULATOR PCB
z
C6 943101101290D TRANS,POWERAVR1513/E3,(85.8X63) E3 CLT5U051ZU 1 *
z
C6 943101101300D TRANS,POWERAVR1513/E2,(85.8X63) E2 CLT5U051ZE 1 *
z
C6 943101101310D TRANS,POWERAVR1513/E1C,(85.8X63) E1C CLT5U051ZH 1 *
C7 nsp 2PWIREASS'Y(100MM) E2 CWZPM5003TW91A 1
P1 943419100450D PANEL,SUB CGR1A533Z 1 *
P2 943416100690D WINDOW,FL CGU1A462Z 1 *
P3 943412100710D KNOB,VOLUME BK CBN1A263 1 *
NOTE :
Please change the destination-resistors when changing 1513E3 (943639100070D) to other destination.
Please refer to destination-resistors. (82 page)
(SCHEMATIC DIAGRAMS : 7/9)
R917
1513 E3 4.7K
1513 E2 OPEN
1513 E1C 10K

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
