Denon AVR-1513 Service Manual

61
LEVEL DIAGRAM
2CH IN 0dB
(200mV)
-10dB
-20dB
10dB
20dB
30dB
40dB
FRONT
AUDIO IN
A/D
DSP
D/A
DIR
DIGITAL
A/D IN
REV AMP
A/D IN
REV AMP
D/A OUT
LPF
4.47Vrms/8ohm
H/P OUT
SPK OUT
NJU72340AFH3
PRE AMP1
ELECTRIC
VOLUME
ATT
FRONT
POWER AMP
A/D
-20dBFS
-30dBFS
0dBFS
-10dBFS
-2.78dB
+1.77dB
-2dB
VOL 00
+29dB
-24dB
SPK OUT
FRONT
H/P OUT
282mVrms
CS42528
0dBFS=5.6Vpp
DIFF. INPUT
=1.98Vrms
-40dBFS
CS42528
AD IN=145mV
(A/D IN)
-22.78dBFS
D/A
CS42528
0dBFS=5Vpp
DIFF. OUT
=1.77Vrms
-30dBFS
0dBFS
-10dBFS
-40dBFS
0dB
-10dB
-20dB
10dB
20dB
30dB
40dB
+1dB
+1.77dB
-20dBFS(DIG.IN)
-22.78dBFS
(A/D IN)
/33ohm
FULL SCALE LEVEL=2Vrms
DOLBY LIMIT LEVEL (ALL ch-3dBFS)
GAIN setting of MASTER VOL 00dB
-SW:YES(ANALOG)
-SW:YES(DIGITAL)
-SW:NONE(ANALOG)
-SW:NONE(DIGITAL)
+1.77dB
-34.78dBFS
(A/D IN)
+13dB
+10dB
+1.77dB
-32dBFS(DIG.IN)
=+1dB
=-2dB
=+13dB
=+10dB
FRONT ch

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
