Denon AVR-1513 Service Manual

116
POWER PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC201 00D2630801004 I.C,REGULATOR HVINJM7812FA
IC202 00D2630641002 I.C,REGULATOR HVINJM7912FA
IC203 231010031706S REGULATOR (5V OUTPUT LOW DROP) HVIKIA278R05PI
IC204 00D2631162014 REGULATOR (5V OUTPUT LOW DROP) HVIKIA78R05PI
Q2001 00MHT30001000 TR KTC3199Y HVTKTC3199YT
Q2002 963216500060S T.R,RT1N144C(10K-47K) E3 CVTRT1N144C
Q2003 00MHT30001000 TR KTC3199Y HVTKTC3199YT
D2001-2004 00D9630328409 DIODE,RECTIFIERS CVD1N4007ST
D2006 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D2008 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D2009 943203003170S DIODE,BRIDGE HVDGBJ606
D2031 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D2032-2037 00D9630328409 DIODE,RECTIFIERS CVD1N4007ST
D2038 00D9430182609 DIODE,SWITCHING CVD1SS133MT
RESISTORS GROUP
z
R2001-2004 943125500050S RES,METALFILM1W5%(SMALL,PILKOR) CRG1SANJR47RTP *
z
R2005-2008 943125500020S RES,METALFILM1W5% CRG1SANJR22RTP
R2031 nsp RES,M-OXIDEFILM(1W/120ohm) CRG1SANJ121RT
R2032 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R2033 nsp RES,CHIP(1608/5%/10Kohm) CRJ10DJ103T
R2034 00MNN05203610 RES,CHIP(1608/5%/20Kohm) CRJ10DJ203T
R2035 nsp RES,CHIP(1608/5%/4.7Kohm) CRJ10DJ472T
R2036 nsp RES,CARBON(1/4W,22ohm,J) CRD25TJ220T
R2037 00MNN05473610 RES,CHIP(1608/5%/47Kohm) CRJ10DJ473T
CAPACITORS GROUP
C2002 943134010470S CAP,ELECT(50V/0.1uF) CCEA1HH0R1T
C2003-2008 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT
C2009 943134010620S CAP,ELECT(25V/4700uF) CCEA1EH472E
C2013 00D9430103905 CAP,ELECT(16V/470uF) CCEA1CH471T
C2014 943134001290S CAP,ELECT(25V/2200uF) CCEA1EH222E
C2017 00D9430062101 CAP,ELECT(16V/100uF) CCEA1CH101T
C2018 943134010600S CAP,ELECT(16V/3300uF) CCEA1CH332E
C2021 00D9430062101 CAP,ELECT(16V/100uF) CCEA1CH101T
C2031 nsp CAP,CHIP(1608,50V/0.01uF) CCUS1H103KC
C2032 00D9430062101 CAP,ELECT(16V/100uF) CCEA1CH101T
C2033 nsp CAP,CHIP(1608,50V/0.01uF) CCUS1H103KC
C2034 943134010600S CAP,ELECT(16V/3300uF) CCEA1CH332E
C2035 943134010470S CAP,ELECT(50V/0.1uF) CCEA1HH0R1T
C2036 943134010530S CAP,ELECT(50V/1uF) CCEA1HH1R0T
C2037 nsp CERAMIC CAP 0.022uF 50V ZF CCFT1H223ZF
z
C2039 943132500020S CAP,CERAMIC(400VY-CAP) CCKDHS222ME
OTHERS PARTS GROUP
BK201,202 nsp BRACKET,PCB(A) CMD2A188
BK204,205 nsp BRACKET,PCB CMD1A569
CN201 nsp WAFER/STRAIGHT/2.5mm/7P CJP07GA01ZY
CN202 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/13PIN CJP13GI288ZY
CN203 nsp WAFER,2P,3.96mm CJP02KA060ZY
CN204 nsp WAFER,2P,7.92mm CJP02GA89ZY
CN205 nsp LOCK-WAFER/STRAIGHT/2MMPITCH/5PIN CJP05GI288ZY *
ET201 nsp PALTE,EARTH HJT1A025
z
F2001 90M-FS001430R FUSE(218Series,250V/6.3A) KBA2C6300TLEY
z
RY201 943682004660S RELAY,G5PA-1,DC6V,1C1P CSL1E002ZE

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
