Denon AVR-1513 Service Manual

68
11.L-OUT
10.R-OUT
9.VCC
8.SCLK 7.SDIO
6./CE 5./RST 4.INT
3.CH_GND 2.CH_GND
1.CH_GND
BN508
CUP12425Z_2
AVR1513 E3
AVR1513 E2
AVR1513 E1C
AVR1613 E3
AVR1713 E3
AVR1713 E2
AVR1713 E1C
AVR1713 K
AVR1723 E1C
R5601
R5602
*TUNER MODULE OPTION.
R5603
R5604
R5605
R5606
J5674
J5676 J5675
TU500
BN508
TUNER
(FOIL SIDE)
TUNER
(COMPONENT SIDE)
*TUNER MODULE OPTION.
R5606
R5605
R5604
R5603
R5602
R5601
AVR1723 E1C
AVR1713 K
AVR1713 E1C
AVR1713 E2
AVR1713 E3
AVR1613 E3
AVR1513 E1C
AVR1513 E2
AVR1513 E3
11.L-OUT 10.R-OUT 9.VCC 8.SCLK 7.SDIO 6./CE 5./RST 4.INT 3.CH_GND 2.CH_GND 1.CH_GND
BN508
R5601 R5602 R5603 R5604 R5605 R5606
PORTABLE
(FOIL SIDE)
PORTABLE
(COMPONENT SIDE)
C1045
JK102
C1060
C1042
BN11B
1.MINI L 2.AGND
3.MINI R
4.+12V
5.-12V
CUP12423Z-3
J1055
J1060
J1058
NO PARTS
NO PARTS
NO PARTS
IC102
C1061
R1052
R1051
R1050
R1049
C1062
R1048
R1047
R1056
R1055
C1046 C1047
C1044
C1043
C1063
R1063 D1018 D1017
C1064
430
5.-12V 4.+12V 3.MINI R 2.AGND 1.MIN L
HEADPHONE
(COMPONENT SIDE)
HEADPHONE
(FOIL SIDE)
CN104
JK104
LUG13
BN13B
C1067
C1065
1.D GND
2.D GND 3.H/P DET
2.A GND 3.H/P L
1.H/P R
CUP12423Z-4
NO PARTS NO PARTS
R1057
C1072
C1071
C1066
C1068
C1069
L6007
C1424
L6008
C1083
C1084
1.H/P R 2.A GND 3.H/P L
1.D GND
2.D GND
3.H/P DET
USB
(COMPONENT SIDE)
USB
(FOIL SIDE)
JK101
BN104
C1078
C1052
2.USBD+
1.VBUS
3.USBD-
4.DGND
5.DGND
CUP12423Z-5
J1041
J1054
NO PARTS
NO PARTS
D1020
D1019
L1003
L1004
L1005
C1053
C1051
C1050
D1011
D1009 D1010
L1009
L1008
D1008
R1040
R1038
R1039
C1048
C1049
430
POWER KNOB
(COMPONENT SIDE)A
POWER KNOB
(FOIL SIDE)
C1040
BN103
LUG12
D1012
SW101
2.MCU +5V
1.D GND
3.GRN LED 4.RED LED 5.PWR KEY
CUP12423Z-6
POWER
NO PARTS
C1054
C1055
C1056 C1057
D1013 D1014
R1044
Q1011
Q1008
Q1009
Q1012
R1041
R1042
R1043
WIRE HOLE
5.PWR KEY
4.RED LED 3.GRN LED
1.D GND
2.MCU +5V
FOR HDMI FFC CABLE
(COMPONENT SIDE)
FOR HDMI FFC CABLE
(FOIL SIDE)
FOR HDMI FFC CABLE
FOR HDMI FFC CABLE
BK103
181716151413121110987654321
M
L
K
J
I
H
G
F
E
D
C
B
A
鉛フリー半田
半田付けには、鉛フリー半田 (Sn-Ag-Cu) を使用してください。
Lead-free Solder
When soldering, use the Lead-free Solder (Sn-Ag-Cu).

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
