Denon AVR-1513 Service Manual

118
MAIN PCB UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
Q5101,5102 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5103 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5104 90M-HT800120R TR KTC3114A HVTKTC3114A
Q5105 90M-HT400490R T.R,POWER HVT2SD2390
Q5106 90M-HT200440R T.R,POWER HVT2SB1560
Q5107 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5108 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5201,5202 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5203 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5204 90M-HT800120R TR KTC3114A HVTKTC3114A
Q5205 90M-HT400490R T.R,POWER HVT2SD2390
Q5206 90M-HT200440R T.R,POWER HVT2SB1560
Q5207 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5208 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5301,5302 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5303 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5304 90M-HT800120R TR KTC3114A HVTKTC3114A
Q5305 90M-HT400490R T.R,POWER HVT2SD2390
Q5306 90M-HT200440R T.R,POWER HVT2SB1560
Q5307 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5308 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5401,5402 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5403 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5404 90M-HT800120R TR KTC3114A HVTKTC3114A
Q5405 90M-HT400490R T.R,POWER HVT2SD2390
Q5406 90M-HT200440R T.R,POWER HVT2SB1560
Q5407 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5408 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5501,5502 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5503 943213500150S NPN,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSC1845FTA *
Q5504 90M-HT800120R TR KTC3114A HVTKTC3114A
Q5505 90M-HT400490R T.R,POWER HVT2SD2390
Q5506 90M-HT200440R T.R,POWER HVT2SB1560
Q5507 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5508 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5601-5604 943213500160S T.R,RT1N237C(2.2K-47K) CVTRT1N237C *
Q5701 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5702 943211500150S PNP,TO-92,LOWNOISE,HFE:300-600,FAILCHILD CVTKSA992FTA *
Q5703 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5704 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5705,5706 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
Q5707 943212500020S HighVoltagePNPTransistors(SOT-23) CVTMMBT5401
Q5708 943214500040S HighVoltageNPNTransistors(SOT-23) CVTMMBT5551
D5102 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5103 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5104 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5105,5106 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5202 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5203 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5204 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5205,5206 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5302 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5303 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5304 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5305,5306 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5402 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5403 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5404 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5405,5406 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5502 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5503 00D9430182609 DIODE,SWITCHING CVD1SS133MT
D5504 90M-HD302390R DIODE,ZENER,1/2W,3.3V CVDZJ3.3BT
D5505,5506 00D9430182609 DIODE,SWITCHING CVD1SS133MT

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
