Denon AVR-1513 Service Manual

60
POWER BLOCK DIAGRAM
MAIN+B
MAIN-B
AC CORD
RELAY
!
!
!
MAIN TRANS
SUB TRANS
S2 TOTAL : 370.2mA
S3 TOTAL : 2454.9mA
!
!
S5(FILAMENT)
S4(FL+Vdisp)
S3(DSP,XM,HDMI)
S2(+12V,-12V)
S1(AMP+B,-B)
NJM7812
NJM7912
VOLUME(NJU72340A)
MTZ7.5B
3.3V
MTZ7.5B
FILAMENT AC
FL DRIVER
MCU(ST)
POWER RELAY
OPAMP x 1
OPAMP x 3
D/A OUT
Portable IN
VOLUME IC(NJU72340A)
RELAY*4
145.1mA
25mA
7.5mA
21mA
KIA7805BPI
NJM2595
TUNER
50mA
OPAMP
NJM2595(CVBS)
22mA
BA4510
15mA
OPAMP x 2
CS42528(VA)
37.5mA
KIA278R05PI
CS42528(VLC)
1mA
CS42528(VLS)
13mA
FLASH(MX25L8006)
20mA
SDRAM
150mA
TC74VHC157
50mA
CS497024
(VDDA_PLL)
3.5mA
CS497024(VDDIO)
120mA
CS42528(VD),(VARX)
122.5mA
3.3V
ADV7623(TVDD),AD8195(234mA)
546mA
MX25L8006EM2I-12G(20mA),ADV7623(DVDDIO)
22mA
5VD, 1056.5mA
26.4mA
545mA
39.6mA
14.3mA
350mA
6.6mA
ADV7623(TXPVDD)
ADV7623(CVDD)
ADV7623(TXPLVDD)
ADV7623(TXAVDD)
ADV7623(PVDD)
ADV7623(DVDD)
CS497024(DVDD)
350mA(TYPICAL)
KIA78R05PI
Vdisp(+37V)
DCDC
1481.9mA
KIA7905PI
KIA7805BPI
KIA7805BPI
5VH, 672.6mA
OPEN OPEN
OPEN
1.8V/3A
49mA(PEAK)
163mAac
35uA (Standby Mode)
5mA
41.7mA
150mA
GBJ806
GBJ606
47.1mA
5mA
3V3D
3V3H
55mA
HP_DET
1V8H
20mA
AD8195
NJM2845DL133
POWER RELAY
2
4
3
1
2
4
3
1

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
