Denon AVR-1513 Service Manual

65
WIRING DIAGRAM
FRONT PCB
3P
BN13B
3P
BN13A
3P
HEADPHONE
PCB
PCB
CN104
KNOB PCB
POWER
23P
CN101
MAIN PCB
POWER PCB
DIGITAL PCB
23P
CN97
7P
CN95
5P
BN94
5P
CN205
3P
BN505
7P
CN102
2P
CN204
2P
CN203
3P
CN503
AC CORD
FRONT <-> DIGITAL
HEADPHONE-FRONT
HEADPHONE <- MAIN
POWER<-DIGITAL
POWER<-AC IN
13P
CN90
13P
BN501
MAIN->DIGITAL
MAIN->DIGITAL
7P
BN502
F-HDMI
23P
CN9A
23P
CN9B
TUNER
PCB
REGULATOR PCB
CN202
7P
CN201
TRANS -> POWER
REGUL.<- DIGITAL
TRANS
POWER
TRANS POWER -> FRONT
POWER KNOB<->FRO NT
TRANS POWER->MAIN
TRANS POWER -> REGUL.
5P
5P
PORTABLE PCB
5P
5P
HDMI <-> DIGITAL
PORT.-FRONT
BN103
CN103
BN11B
BN11A
13P
BN99
13P

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
