Denon AVR-1513 Service Manual

P3
P2
P13
M5
P14
P9
P5
P1
P6
P4
M2
P12
P11
P11
M11
P10
P10
C6
M7
M4
C2-1
C3-1
C4-1
C1-1
P7
S10
P8
M3
M6
M10
M8
M8
M9
M9
P15
C7
C1-3
M1
C1-4
C1-2
C4-2
C2-2
C2-3
C2-4
C3-2
C2-5
C1-5
M3
S6
S12
x5
S8
x2
S4
x7
S4
x4
S4
x2
S4
S4
x2
S8
x2
S2
S8
x2
S9
x2
S8
x2
S3
x2
S8
S13
x4
S3
x6
S3
S8
x4
S3
S15
S15
S10
x4
x6
S3
S8
S1
x15
S7
x2
S5
S7
S5
S7
S5
S4
x2
S4
P13
P14
z
S11
x3
S8
S16
x3
C1-6
Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by
the manufacturer.
WARNING:
印の部分は安全を維持するために重要
な部品です。従って交換時は必ず指定の
部品を使用してください。
EXPLODED VIEW
85

Denon AVR-1513 Specifications

General

Receiver type	-
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Power output per channel (1KHz@6 Ohm)	110 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Composite video in	2
Digital audio optical in	1
Connectivity technology	Wired
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Radio Data System (RDS)	Yes
Preset stations quantity	56
Supported video modes	1080p, 720p
Analog signal format system	NTSC, PAL
Display	LCD
Product color	Black
Audio decoders	Dolby Pro Logic II, Dolby TrueHD, DTS 96/24, DTS Neo:6, DTS-HD
Apple docking compatibility	Not supported
Graphical user interface (GUI) language	English
AC input voltage	220-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7800 g
