Denon AVR-X500 Service Manual

17
1. µcom/DSP/OSDVersiondisplaymode
1.1. Operationspecications
µcom/DSP/OSDversiondisplaymode:
Whenthesetisstartedupinthismode,theversioninformationisdisplayed.
Starting up:
Pressthe
X
buttontoturnonthepowerwhilepressingthe"DIMMER"and"STATUS"buttons.
Now,pressthe"STATUS"buttontothedisplaythe2nditeminformationontheFLDisplay.
1.2. Display Order
q
Modeldestinationinformation→
w
Main-µcomversion→
e
DSPversion→
r
OSDversion
Display State
q
Modeldestinationinformation
AVR-E200E3,E3Bmodel
A V R - E 2 0 0 E 3
AVR-X500E2,E1model
A V R - X 5 0 0 E 2
AVR-X500E1Cmodel
A V R - X 5 0 0 E 1 C
w
Main-µcomversion
M a i n : * * . * *
e
DSPversion
D S P . * . * . *
r
OSDversion
O S D : * * . * *
Cleared of mode:
Pressthe
X
buttontoturnthepoweroff.
1.3. Error display
Seethefollowingtableforeach"Errorinformation"displayanditscontents(status).
Condition - State
DSPNG WhenDSPboot,executingDSPresetmakestobecomeserror.
D S P E R R O R 0 1
DSPOK (Noerrordisplay,versiondisplayonly)

Denon AVR-X500 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Speaker selector	No
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Audio (L/R) in	3
Composite video in	2
Ethernet LAN (RJ-45) ports	0
Number of HDMI outputs	1
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Multichannel pre out connectivity	RCA
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Cables included	AC

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7900 g
