Denon AVR-X500 Service Manual

65
WIRING DIAGRAM
AVRE200/X500 WIRING DIAGRAM
FRONT PCB
3P
BN13B
3P
BN13A
3P
H/P PCB
CN104
KNOB PCB
POWER
23P
CN101
MAIN PCB
ST-BY PCB
DIGITAL PCB
23P
CN97
7P
CN95
5P
BN94
5P
CN205
3P
BN505
7P
CN102
2P
CN204
2P
CN203
3P
CN503
AC CORD
FRONT <-> DIGITAL
H/P-FRONT
H/P <- MAIN
ST-BY<-DIGITAL
ST-BY<-AC IN
13P
CN90
13P
BN501
MAIN->DIGITAL
MAIN->DIGITAL
7P
BN502
F-HDMI
PCB
23P
CN9A
23P
CN9B
REGULATOR PCB
CN202
7P
CN201
TRANS -> ST-BY
REGUL.<- DIGITAL
TRANS
TRANS -> FRONT
POWER KNOB <->FRONT
TRANS->MAIN
TRANS -> REGUL.
5P
5P
PORTABLE PCB
5P
5P
HDMI <-> DIGITAL
PORT.-FRONT
BN103
CN103
CN11B
CN11A
9P
BN99
9P

Denon AVR-X500 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Speaker selector	No
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Audio (L/R) in	3
Composite video in	2
Ethernet LAN (RJ-45) ports	0
Number of HDMI outputs	1
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Multichannel pre out connectivity	RCA
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Cables included	AC

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7900 g
