Denon AVR-X500 Service Manual

95
Pin Pin Name Symbol I/O Pullup STBY stop Function
36 PA2 NC O(L) - - - NC
37 PA3 NC O(L) - - - NC
38 VSS_4 - - - - GND
39 VDD_4 - - - - 3.3V
40 PA4 DSP_CS O - O/L O/L DSP Chip Select
41 PA5 DSP_CLK O D3VPu O/L O/L DSP_CLK
42 PA6 DSP_MISO I D3VPu O/L O/L DSP MISO
43 PA7 DSP_MOSI O - O/L O/L DSP MOSI
44 PC4 NC O(L) - - - NC
45 PC5 NC O(L) - - - NC
46 PB0 DIR_MISO I - O/L O/L DIR_MISO
47 PB1 DIR_CLK O D3VPu O/L O/L DIR_CLK
48 PB2 / BOOT1 BOOT1 I - - - GND
49 PF11 DIR_MOSI O - O/L O/L DIR MOSI
50 PF12 DSP_RST O - O/L O/L DSP Reset
51 VSS_6 - - - - GND
52
VDD_6 - - - - 3.3V
53 PF13 DSP_MODE_SEL I/O PullDown O/L O/L DSP_MODE_SEL
54 PF14 CODEC_MUTE I(FT) - O/L O/L CODEC Mute Detect (*FT = 5V tolerant)
55 PF15 DIR_RST O - O/L O/L DIR Reset
56 PG0 DIR_CE O - O/L O/L DIR Chip Select
57 PG1 DSP_SPC1_IRQ I D3VPu O/L O/L DSP INTERRRUPTQ
58 PE7 DSP_PCP_BSY I D3VPu O/L O/L DSP BSY
59 PE8 NC O(L) - - - NC
60 PE9 HDMI_SW O - O/L O/L HDMI Audio Data MCLK Select SW
61 VSS_7 - - - - GND
62 VDD_7 - - - - 3.3V
63 PE10 NC O(L) - - - NC
64 PE11 HDMI_SPI_MISO I - I O/L HDMI OSD DATA input
65 PE12 HDMI_SPI_MOSI O - O/L O/L HDMI OSD DATA output
66 PE13 HDMI_SPI_CS O +3VHPu O/L O/L HDMI OSD Chip Select
67 PE14 HDMI_SPI_CLK O - O/L O/L HDMI OSD Clock
68 PE15 HDMI_SPI_HOLD O - O/L O/L HDMI OSD HOLD Control
69 PB10
HDMI_RST O - O/L O/L HDMI Reset
70 PB11 NC O(L) - - - NC
71 VSS_1 - - - - GND
72 VDD_1 - - - - 3.3V
73 PB12 RESERVED O(L) - - - RESERVED
74 PB13 RESERVED O(L) - - - RESERVED
75 PB14 HDMI_INT_TX_7623 I +3VHPu I O/L HDMI INT TX interrupt
76 PB15 RESERVED O(L) - - - RESERVED
77 PD8 HDMI_TXEN O - O/L O/L FRONT HDMI BUFFER(AD8195) Output Enable
78 PD9 NC O(L) - - - NC
79 PD10 NC O - O/L O/L Option(STANDBY CEC MODE Control)
80
PD11 HDMI_INT I +3VHPu I O/L HDMI INT interrupt
81 PD12 HDMI_INT2 I +3VHPu I O/L HDMI INT2 intreeupt
82
PD13 HDMI_SDA I/O +3VHPu O/L O/L HDMI SDATA
83 VSS_8 - - - - GND
84 VDD_8 - - - - 3.3V
85 PD14 HDMI_SCL O - O/L O/L HDMI SCL
86 PD15 PWR_FAIL_PROTECT I M3VPu O/L O/L +12V/-12V CHECK PROTECTION
87 PG2 THERMALDET_B I M3VPu O/L O/L TEMPERATURE PROTECTION
88 PG3 THERMALDET_A I M3VPu O/L O/L TEMPERATURE PROTECTION
89 PG4 ASO_DET I M3VPu O/L O/L ASO_DETECT
90 PG5 POWER_ON O - O/L O/L POWER RELAY Control
91 PG6 NC I - I O/L Option(CEC MODE Interrupt)
92 PG7 VOL+ I - O/L O/L VOLUME UP
93 PG8 VOL- I - O/L O/L VOLUME DOWN
94 VSS_9 - - - - GND
95 VDD_9 - - - - 3.3V
96 PC6 RESERVED O(L) - - - RESERVED
97 PC7 VFD_CE O - O/L O/L VFD_CE
98 PC8 VFD_CLK O - O/L O/L VFD_CLK
99 PC9 RESERVED O(L)
- - - RESERVED
100 PA8 VFD_DATA O - O/L O/L VFD_DATA
101 PA9 UPDATE_TX O - O/L O/L UPDATE TX

Denon AVR-X500 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Speaker selector	No
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Audio (L/R) in	3
Composite video in	2
Ethernet LAN (RJ-45) ports	0
Number of HDMI outputs	1
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Multichannel pre out connectivity	RCA
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Cables included	AC

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7900 g
