Denon AVR-X500 Service Manual

61
LEVEL DIAGRAM
2CH IN 0dB
(200mV)
-10dB
-20dB
10dB
20dB
30dB
40dB
FRONT
AUDIO IN
A/D
DSP
D/A
DIR
DIGITAL
A/D IN
REV AMP
A/D IN
REV AMP
D/A OUT
LPF
4.47Vrms/8ohm
H/P OUT
SPK OUT
NJU72340AFH3
PRE AMP1
ELECTRIC
VOLUME
ATT
FRONT
POWER AMP
A/D
-20dBFS
-30dBFS
0dBFS
-10dBFS
-2.78dB
+1.77dB
-2dB
VOL 00
+29dB
-24dB
SPK OUT
FRONT
H/P OUT
282mVrms
CS42528
0dBFS=5.6Vpp
DIFF. INPUT
=1.98Vrms
-40dBFS
CS42528
AD IN=145mV
(A/D IN)
-22.78dBFS
D/A
CS42528
0dBFS=5Vpp
DIFF. OUT
=1.77Vrms
-30dBFS
0dBFS
-10dBFS
-40dBFS
0dB
-10dB
-20dB
10dB
20dB
30dB
40dB
+1dB
+1.77dB
-20dBFS(DIG.IN)
-22.78dBFS
(A/D IN)
/33ohm
FULL SCALE LEVEL=2Vrms
DOLBY LIMIT LEVEL (ALL ch-3dBFS)
GAIN setting of MASTER VOL 00dB
-SW:YES(ANALOG)
-SW:YES(DIGITAL)
-SW:NONE(ANALOG)
-SW:NONE(DIGITAL)
+1.77dB
-34.78dBFS
(A/D IN)
+13dB
+10dB
+1.77dB
-32dBFS(DIG.IN)
=+1dB
=-2dB
=+13dB
=+10dB
FRONT ch

Denon AVR-X500 Specifications

General

Receiver type	-
Frequency range	10 - 100000 Hz
Pre-out channels	1 SW
Speaker selector	No
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	5.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	140 W
Power output per channel (20-20KHz@8 Ohm)	75 W
HDMI in	4
Audio (L/R) in	3
Composite video in	2
Ethernet LAN (RJ-45) ports	0
Number of HDMI outputs	1
Connectivity technology	Wired
Speakers connectivity type	Clamp terminals
Multichannel pre out connectivity	RCA
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Product color	Black
Audio decoders	Dolby Digital EX, Dolby Pro Logic IIx, Dolby TrueHD, DTS 96/24, DTS-ES, DTS-HD Master Audio
Apple docking compatibility	Not supported
Number of products included	1 pc(s)
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	330 W
Cables included	AC

Weight and Dimensions

Depth	319 mm
Width	434 mm
Height	151 mm
Weight	7900 g
