Denon DCD-F109 Service Manual

13
DISASSEMBLY
• Disassemble in order of the arrow in the following gure.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the reassembling, observe "Caution concerning disassembly and assembly!".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
DOOR
Refer to
"DISASSEMBLY
1. DOOR"
and
"EXPLODED VIEW"
LOADER PANEL
(Ref. No. of EXPLODED VIEW : 14)
POWER TRANS
Refer to
"DISASSEMBLY
5. POWER TRANS"
and
"EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : 24)
POWER PCB
Refer to
"DISASSEMBLY
7. POWER PCB"
and
"EXPLODED VIEW"
POWER PCB
(Ref. No. of EXPLODED VIEW : 20)
MAIN PCB
Refer to
"DISASSEMBLY
4. MAIN PCB"
and
"EXPLODED VIEW"
MAIN PCB
(Ref. No. of EXPLODED VIEW : 23)
CD MECHANISM ASSY
Refer to
"DISASSEMBLY
3. CD MECHANISM ASSY"
and
"EXPLODED VIEW"
CD MECHA
(Ref. No. of EXPLODED VIEW : 16)
CABINET TOP
AUDIO PCB
Refer to
"DISASSEMBLY
6. AUDIO PCB"
and
"EXPLODED VIEW"
AUDIO PCB
(Ref. No. of EXPLODED VIEW : 21)
DC-DC PCB
(Ref. No. of EXPLODED VIEW : 23)
FRONT PANEL ASSY
Refer to
"DISASSEMBLY
2. FRONT PANEL ASSY"
and
"EXPLODED VIEW"
FRONT PCB
(Ref. No. of EXPLODED VIEW : 19)

Denon DCD-F109 Specifications

General

Audio formats supported	MP3, WMA
CD-RW playback	Yes
CD changer	No
Device type	HiFi CD player
Product color	Black
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	264 mm
Width	250 mm
Height	82 mm
Weight	2800 g
