19
(2) Remove the screws.
(3) Remove the screw.
7. POWER PCB
Shooting of photograph: A
Shooting of photograph: C
CABINET TOP
AUDIO PCB
→
POWER PCB
→
Proceeding :
Please refer to "EXPLODED VIEW" for the disassembly method of POWER PCB.
