Denon DCD-F109 Service Manual

78
PARTS LIST OF P.C.B. UNIT
z
Parts indicated by "nsp" on this table cannot be supplied.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe modelE1C : China model
E1C : China model JP : Japan model
MAIN P.W.B. UNIT ASS'Y
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC11 963243101240S IC,CPU MICRO PROCESS,TMP92FD23AFG 8952109000020 *
IC12 963239100780S IC,LINEAR-RESET,NCP300LSN30T1 TSOP-5 J125030050010S *
IC13 963248101360S IC,MEMORY-EEPROM,M95010W-SO8N J000950100010S *
IC14 23981000350AS IC,LINEAR-DRIVER,IP4001CR 28SSOPH-375 J127400100010S
IC15 963243101250S IC,CPU MICRO PROCESS,TMP92FD28AFG 8952109000030 *
IC16 nsp IC,LOGIC-DECODER MFI337S3959 J044337395910S
IC17 245010015000S IC,LOGIC-DECODER,TC94A92FG-301 J044949200010S
IC20 963231101210S IC,LINEAR-REGULATOR,IL1117-1.5 J126111715070S *
IC21 nsp IC,LINEAR-DRIVER NCP380HMU J127380150010S
IC81 00D2621230901 IC,LOGIC,KIC7SH04FU J040704000010S *
IC605 231810041507S IC,LINEAR-REGULATOR,SI-8005Q-TL J126800500010S
IC606,607 00D2623676903 IC,LOGIC,TC74VHCT08AFTS1-TBB J040740800350S
IC608 963239007790M IL1117_5.0 SOT-223 5.0V 1A LOW DROPOUT J126111750010S
Q202 00D9630148508 CHIP TRS. KTA1504S 0.15W SOT23 REEL J520015040150S
Q613,614 00D9600285006 CHIP TRKRC104S (ND)/SOT-23 REEL J522104S00210S
D201,202 00D2760846900 D,SCHOTTKY RB060M-30 K120060300010S
D203 00D9600197000 D,SWITCHING KDS160(UF) K005016000010S
D206 00M-HD201320R D,SWITCHING,1SS355TE-17(ROHM) K005035500020S
D601 00D2760846900 D,SCHOTTKY RB060M-30 K120060300010S
D606,607 00D9600197000 D,SWITCHING KDS160(UF) K005016000010S
RESISTORS GROUP
R557 nsp R,THICK 0-J,1/10W C200000060201S
R813 nsp COIL,BEAD CBW160808U121T D340160811210S
C101-104 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C105 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C106 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C107,108 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C109 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C110 nsp C,CERAMIC T.C COG18PF-J/50V D010180167160S
C111 nsp
C,CERAMIC CHIP T.C COG22PF-J/50V-
1608REEL
D010220167160S
C112 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C113,114 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C115,116 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C119 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C120 nsp C,CERAMIC 4.7UF-K/6.3V D011475571160S
C123 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C151 00D9630325004 C,ELECT 100UF-MVG/6.3V D050101081650S
C201 nsp C,CERAMIC 2200PF-K/50V D011222777160S
C202,203 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C204 nsp C,CERAMIC 0.01UF-K/50V D010103777160S
C205 nsp C,CERAMIC 4700PF-K/50V D011472777160S
C206 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C207 nsp C,CERAMIC X7R0.015UF-K/50V D011153777160S
C208 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C210,211 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C213 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C214 nsp C,CERAMIC CHIP 0.033UF-Z/50V-1608REEL D011333597160S
C215 nsp C,CERAMIC 5600PF-K/50V D011562777160S
C216 nsp C,CERAMIC 470PF-J/50V D010471167160S

Denon DCD-F109 Specifications

General

Audio formats supported	MP3, WMA
CD-RW playback	Yes
CD changer	No
Device type	HiFi CD player
Product color	Black
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	264 mm
Width	250 mm
Height	82 mm
Weight	2800 g
