Denon DCD-F109 Service Manual

55
PARTS LIST OF EXPLODED VIEW
z
Parts indicated by "nsp" on this table cannot be supplied.
z
P.W.B. ASS'Y indicated by "nsp" on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts list and order replacement
parts.
z
Parts indicated by the "
★
" mark are not illustrated in the exploded view.
z
The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
Note:
The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model
E1C : China model JP : Japan model
BK : Black model SP : Premium Silver model
Ref. No. Part No. Part Name Remarks Q'ty New
- nsp P.C.B TOTAL ASSY / FRONT E2 7025HD1104021 1 *
20 nsp POWER PCB E2 7028071962020 1 *
21 nsp AUDIO PCB E2 7028071963020 1 *
19 nsp FRONT PCB E2/JP 7028071961010 1 *
- nsp P.C.B TOTAL ASSY / MAIN E2 7025HD1104020 1 *
23 nsp MAIN PCB E2 7028071951020 1 *
22 nsp DC-DC PCB E2/JP 7028071952010 1 *
1 963416100800D WINDOW,DISPLAY 5077213353000S 1 *
2 00D9630051310 LENS 3710210023001S 1
d
3 963402102820D PANEL,FRONT(AL) BK E2 3067215608010S 1 *
3 963402102830D PANEL,FRONT(AL) SP E2/JP 3067215608000S 1 *
4 963443100530D PANEL,INNER(BK) E2 3067215631000S 1 *
4 963443100540D PANEL,INNER(SP) E2/JP 3067215631100S 1 *
5 963411101840D BUTTON-ASSY,POWER (BK) E2 5098215041000SZ 1
5 963411101850D BUTTON-ASSY,POWER (SP) E2/JP 5098215041100SZ 1
6 963411102400S BUTTON,1KEY (BK) E2 5097215031000S 1 *
d
6 963411102410S BUTTON,1KEY (SP) E2/JP 5097215031010S 1 *
d
7 963411102420S BUTTON,3KEY (BK) E2 5097215051000S 1 *
d
7 963411102430S BUTTON,3KEY (SP) E2/JP 5097215051010S 1 *
d
8 963411102440S BUTTON,2KEY (BK) E2 5097215061000S 1 *
d
8 963411102450S BUTTON,2KEY (SP) E2/JP 5097215061010S 1 *
d
9 nsp PLATE,EARTH 4470212516000S 1
10 nsp CHASSIS,MAIN 3200214376000S 1 *
11 nsp STOPPER AC CORD 4380040162010S 1
12 nsp TAPE A710000510000S 0.02
13 nsp CLAMP WIRE(HOLDER L=50) 4330210189000S 1
14 963418013020D PANEL,LOADER(BK) E2 3067215721000S 1 *
14 963418013030D PANEL,LOADER(SP) E2/JP 3067215721100S 1 *
16 943302100130D MECHA,CD MECHA 8030101010010S 1 *
17 963406100100D CHASSIS,BACK(E2) E2 3207214336000S 1 *
17 963406100110D CHASSIS,BACK(JP) JP 3207214336100S 1 *
18 963403100640D CABINET TOP(BK) E2 3007212056010S 1 *
18 963403100650D CABINET TOP(SP) E2/JP 3007212056000S 1 *
24 963101101710S POWER TRANS,MAIN 230V/50HZ E2 8200540230070S 1 *
24 963101101720S POWER TRANS,MAIN 100V/50,60HZ JP 8200540230060S 1 *
25 nsp CUSHION,PCB 4050213375000S 1
26 963432100250D SHEET,HIMELON 1210212079000S 1 *
27 963407100330S FOOT 4000210731000S 4 *
96340710033d
28 963407100220D CUSHION FOOT 4050212815000S 4 *
29 963432100250D SHEET, HIMELON 1210212079000S 1 *
★
30 nsp TAPE ACETATE 1220210789000S 2
★
31 nsp PUSH RIVET SR3.5-5 1560210031000S 1

Denon DCD-F109 Specifications

General

Audio formats supported	MP3, WMA
CD-RW playback	Yes
CD changer	No
Device type	HiFi CD player
Product color	Black
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	264 mm
Width	250 mm
Height	82 mm
Weight	2800 g
