Denon DCD-F109 Service Manual

22
1. SERVICE MODE
(1) AC is turned on while pressing the
5
and
2
button same time on this unit.(Model name display)
1.1. VersionNo.ofmainμ-comDisplaymode
(1) Press the
9
button.
(**** : Version number of main μ-com)
1.2. VersionNo.ofUSBμ-comDisplaymode
(1) Press the
9
button while version No. of main μ-com is displayed.
(**** : Version number of USB μ-com)
1.3. FLD check mode
(1) When display is version No. of USB μ-com and the
9
button is pressed, turn on the entire display is ashing with
an interval of about 1 second.
(2) Press the
9
button again in the turn on each grid of FLD. (Each grid is displayed at interval of 1 second.)
2. CD TEST MODE
(1) AC is turned on while pressing the
5
and
2
button same time on this unit.(Model name display)
(2) Press the
2
and
1
/
3
button same time while version display, FLD check mode and heat runmode.( CD TEST
MODE display)
•
13
ashing
2.1. Disc loading
(1) Press the
5
button to open the tray.
(2) Set a disc on the tray, then press the
5
button again to close the tray.
DCD-F109
Ver xxxx
USB_Ver ****
00 CD TEST MODE
