Denon DCD-F109 Service Manual

15
1. DOOR
(1) You can slide in the arrow direction to pull out the TRAY
.
(2) Detach the DOOR.
CABINET TOP
DOOR
→
Proceeding :

View from bottom
PANEL LOADER

Denon DCD-F109 Specifications

General

Audio formats supported	MP3, WMA
CD-RW playback	Yes
CD changer	No
Device type	HiFi CD player
Product color	Black
USB 2.0 ports quantity	1

Weight and Dimensions

Depth	264 mm
Width	250 mm
Height	82 mm
Weight	2800 g
