Denon S-102 Service Manual

103
S-102
PARTS LIST OF PACKING & ACCESSORIES
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Note: The symbols in the column "Remarks" indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model JP : Japan model
Ref. No. Part No. Part Name Remarks Q'ty New
1 531 210 0230 07D MASTER CARTON for E2 1 *
1 00D 501 2374 017 MASTER CARTON for E3 1 *
1 00D 501 2374 020 MASTER CARTON for JP 1 *
2 00D 502 1143 103 TOP SPACER 1*
3 00D 505 0312 057 CABINET COVER 1 *
4 00D 503 1554 009 CUSHION(L) 1*
5 00D 503 1555 008 CUSHION(R) 1*
6 00D 505 0312 060 CABINET COVER 1
7 00D 9H3 0001 725 CUSHION DSW(BOTTOM) 1
8 00D 9H3 0001 724 CUSHION DSW(UP) 1
9 00D 9H3 0001 721 CUSHION SC(BOTTOM) 1
10 00D 9H3 0001 720 CUSHION SC(UP) 1
11 00D 104 0355 002 SP STAND(EASY) 2 *
12 00D 461 1236 007 PORON (HH48 F10 T1) 4
15 00D 505 0038 030 POLY COVER 1
16 00D 511 4645 000 INST. MANUAL(E2) for E2 1 *
16 00D 511 4646 009 INST. MANUAL(E3) for E3 1 *
16 00D 511 4647 105 INST. MANUAL(J) for JP 1 *
17 nsp S.S.LIST(EX) for E3, E2 1
17 nsp SERVICE STATION LIST for JP 1
18 00D 399 1102 001 REMOCON(RC1073) 1 *
19 nsp POLY COVER 1
20 nsp POLY COVER 1
21 nsp BATTERY (SUM-3) ASS 1
22 00D 203 0380 002 1P PIN CORD (VIDEO) 1
23 00D 231 1152 001 AM LOOP ANTENNA(S) 1
24 00D 395 0026 005 FM ANT. WIRE for E2 1
24 00D 395 0028 003 FM ANT ASS Y(F/WELT) for E3, JP 1
25 00D 461 1237 006 PORON (HH48 F6 T1) 1
26 00D 505 0343 000 ENVELOPE 1
27 0RD 471 3508 028 5X14 CBS-B 4
28 00D 203 2443 002 SP WIRE KIT(NLB193) 1 *
29 00D 204 6794 006 25P D-SUB CABLE 1
30 00D 511 4648 007 SETUP GUIDE 1*
★ 31
nsp WARRANTY (HOME) for E3 1
★ 32
nsp UPC LABEL for E3 1 *
★ 33
00D 517 1506 027 POS LABEL for JP 1 *
★ 34
nsp DATE LABEL for JP 1
★ 35
nsp CONT.CARD(L)SUB ASSY for E3, E2 1
★ 36
nsp GUARANTEE(S)SUB ASSY for JP 1
j
g

Denon S-102 Specifications

General

Audio decoders	Dolby Digital, DTS
RMS rated power	70 W
Audio output channels	2.1 channels
Audio formats supported	MP3, WMA
Tweeter diameter	25 mm
Weight	3800 g
Set width	380 mm
Dimensions (WxDxH)	380 x 93 x 293 mm
Mid-range driver diameter	80 mm
Radio Data System (RDS)	Yes
Optical disc player type	DVD player
Power consumption (standby)	0.3 W
Power consumption (typical)	51 W

Weight and Dimensions

Subwoofer weight	10500 g
Subwoofer dimensions (WxDxH)	408 x 378 x 212 mm
Front speaker dimensions (WxDxH)	76 x 258 x 103 mm
