Denon S-102 Service Manual

92
S-102
EXPLODED VIEW
6
5
4
12
7
9
2
2
10
8
2
13
14
15
46
46
-1
-2
3
-3
-6
-5
-7
-4
-2
-1
-1
4
47
-2
2
2
18
19
20
1
23
24
25
26
27
2
2
30-1
44
30
45
31
32
48
33
34
35
36
37
102
102
101
101
101
103
103
101
104
104
104
104
104
105
106
106
106
108
103
104
109
103
110
107
106
21
3
47
Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by
the manufacturer.
WARNING:




Denon S-102 Specifications

General

Audio decoders	Dolby Digital, DTS
RMS rated power	70 W
Audio output channels	2.1 channels
Audio formats supported	MP3, WMA
Tweeter diameter	25 mm
Weight	3800 g
Set width	380 mm
Dimensions (WxDxH)	380 x 93 x 293 mm
Mid-range driver diameter	80 mm
Radio Data System (RDS)	Yes
Optical disc player type	DVD player
Power consumption (standby)	0.3 W
Power consumption (typical)	51 W

Weight and Dimensions

Subwoofer weight	10500 g
Subwoofer dimensions (WxDxH)	408 x 378 x 212 mm
Front speaker dimensions (WxDxH)	76 x 258 x 103 mm
