Denon S-102 Service Manual

98
S-102
DSW-S102 EXPLODED VIEW
2
18
12
14
16
3
11
101
5
4
5
13
1-4
1-2
15
17
101
101
104
105
106
107
19
20
10
9
6
102
1-1
102
103
7
24
27
28
!
Parts marked with this symbol have critical
characteristics.
Use ONLY replacement parts recommended by
the manufacturer.
WARNING:




Denon S-102 Specifications

General

Audio decoders	Dolby Digital, DTS
RMS rated power	70 W
Audio output channels	2.1 channels
Audio formats supported	MP3, WMA
Tweeter diameter	25 mm
Weight	3800 g
Set width	380 mm
Dimensions (WxDxH)	380 x 93 x 293 mm
Mid-range driver diameter	80 mm
Radio Data System (RDS)	Yes
Optical disc player type	DVD player
Power consumption (standby)	0.3 W
Power consumption (typical)	51 W

Weight and Dimensions

Subwoofer weight	10500 g
Subwoofer dimensions (WxDxH)	408 x 378 x 212 mm
Front speaker dimensions (WxDxH)	76 x 258 x 103 mm
