S-102

PARTS LIST OF EXPLODED VIEW

＊本表に"nsp" と記載されている部品は供給できません。

＊ Parts for which "nsp" is indicated on this table cannot be supplied.

＊本表に"nsp" と記載されている基板 ASS’Y は供給できません。基板 ASS’Y の修理の際には基板部品表を確認のうえ、交換部品を発注してください。

＊

P.W.B. ASS'Y for which "nsp" is indicated on this table cannot be supplied. When repairing the P.W.B. ASS'Y, check the board parts table and order replacement parts.

＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。

＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.

Note: The symbols in the column "Remarks" indicate the following destinations.

E3 : U.S.A. & Canada model E2 : Europe model JP : Japan mode

Ref. No. Part No. Part Name Remarks Q'ty New

1 00D1U-3836D MAIN P.W.B. UNIT ASS'Y(E2) for E2 1 *

1 00D1U-3836E MAIN P.W.B. UNIT ASS'Y(E3) for E3 1 *

1 00D1U-3836F MAIN P.W.B. UNIT ASS'Y(J) for JP 1 *

2 nsp LOC/PWR-DSP P.W.B. UNIT ASS'Y(ALL) 1 *

2-1 - DISPLAY CENT. UNIT 1

2-2 - DISPLAY RIGHT UNIT 1

2-3 - DISPLAY LEFT UNIT 1

2-4 - LOCAL POWER UNIT 1

2-5 - HP OUT UNIT 1

2-6 - AUX IN UNIT 1

2-7 - IF-1 UNIT 1

3 00D 146 2502 103 FRONT PANEL ASSY 1 *

3-1 - FRONT PANEL 1

3-2 - WINDOW 1

4 00D 113 2099 001 POWER KNOB ASSY 1 *

4-1 - POWER KNOB CAP 1

4-2 - KNOB BASE(POWER) 1

5 00D 143 1292 004 LENS(POWER) 1 *

6 00D 113 2094 006 KNOB(PLAY) 1*

7 00D 113 2095 005 KNOB(EJECT) 1*

8 00D 113 2096 004 KNOB(FUNCTION) 1 *

9 00D 113 2098 002 KNOB(STOP) 1*

10 00D 113 2097 003 KNOB(SKIP) 1*

12 00D 461 1298 003 BLIND SHEET 1*

13 00D 431 0452 001 BLIND 1*

14 00D 463 0958 007 SPRING 2

15 nsp FRONT BRACKET 1 *

18 nsp MAIN CHASSIS 1 *

19 00D 104 0351 022 FOOT 4*

20 00D 461 1066 002 FELT 4

21 00D 415 1012 008 PROTECT SHEET 1 *

23 00D 105 1691 108 REAR PANEL 1*

24 00D 216 0125 001 AM FM TUNER(E2) for E2 1

24 00D 216 0125 108 or FM AM TUNER (E2) for E2 1

24 00D 216 0129 007 AM FM TUNER(E3 RDBS) for E3 1

24 00D 216 0129 104 or FM AM TUNER (E3RDBS) for E3 1

24 00D 216 0127 009 AM FM TUNER(J) for JP 1

24 00D 216 0127 106 or FM AM TUNER (J) for JP 1

25 00D 421 0839 009 FAN F410T-12L1C 1

26 nsp FAN BRACKET 1

27 nsp SHIELD BRACKET 1 *

30 FG5HPS1MS DVD MECHA UNIT 1

30-1 00D1U-3807 FEP P.W.B. UNIT 1

31 00D 146 2506 031 TOP COVER for E2 1 *

31 00D 146 2506 044 TOP COVER for E3 1 *

31 00D 146 2506 057 TOP COVER for JP 1 *

32 nsp TOP BRACKET 1 *
