S-102

PARTS LIST OF P.W.B. UNIT

＊本表に"nsp" と記載されている部品は供給できません。

＊ Parts for which "nsp" is indicated on this table cannot be supplied.

＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。

＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.

Note: The symbols in the column "Remarks" indicate the following destinations.

E3 : U.S.A. & Canada model E2 : Europe model JP : Japan model

1U-3836D/E/F MAIN P.W.B. UNIT ASS’Y

Ref. No. Part No. Part Name Remarks Q'ty New

SEMICONDUCTORS GROUP

IC101 00D 262 3708 004 ES6178FF

IC102 00D GEN 8571 B/E ROM SUB ASSY ES29LV160EB-70TGI

IC102 00D GEN 8571 or B/E ROM SUB ASSY W19B160BBT7H

IC103 00D 262 3759 008 K4S641632K-UC60

IC104 00D 262 3402 902 BR24L32F-WE2 +C

IC105 00D 262 3242 900 SN74LV273APW-EL2 +REF

IC108 00D 262 2516 909 SN74LV32APW-EL2 +C

IC109 00D 262 3751 909 BU2360FV-FE2

IC110 00D 262 3046 902 TC7WH157FU +C

IC111 00D 263 1282 907 BD7820FP-E2

IC202 00D 262 3707 908 BR25L640F-WE2

IC203 00D 262 3082 924 BD4730G-TR

IC205 00D 262 2953 902 SN74HCT244APW +C

IC210 00D 262 2813 903 SN74AHCT08PW-EL2 +C

IC211 00D 262 2517 908 SN74LV08APW-EL2 +REF

IC301 00D GEN 8570 SYSTEM ROM SUB ASSY M30627FHPGP

IC303 00D 263 1240 907 BA33B00FP-E2

IC304 00D 263 1278 908 SI-8001FDE

IC305 00D 263 1279 907 SI-8008TM

IC306 00D 263 1278 908 SI-8001FDE

IC401 00D 262 3709 003 ADSP21367KSZ1A1138

IC402 00D 262 3746 008 W9864G2GH-7

IC403 00D GEN 8770 DSP ROM SUB ASSY ES29LV160EB-70TGI

IC403 00D GEN 8770 or DSP ROM SUB ASSY W19B160BBT7H

IC404 00D 263 1281 908 BD9130NV-E2

IC501 00D 262 3757 000 ADAU1328BSTZ1138

IC502 00D 262 3449 004 LC89057W-VF4A

IC503 00D 262 3750 007 LC4064V-75TN100C(S302)

IC504,505 00D 263 0934 900 BA4510F-E2 +C

IC506,507 00D 263 0896 909 NJM2068MD-TE1 +C

IC508 00D 262 2977 946 BA33BC0FP-E2 +REF

IC511 00D 269 0231 009 GP1FAV31RK0F

IC601 00D 263 1245 009 M61531FP

IC602 00D 263 1232 902 NJM79L07UA-TE1

IC603 00D 263 1231 903 NJM78L07UA-TE1

IC604 00D 263 0615 902 BA15218F-DXE2 +C

IC608 00D 263 0995 004 NJM4556AD +T

IC609,610 00D 263 0615 902 BA15218F-DXE2 +C

IC611-613 00D 263 1277 909 RC4580IDR

IC701 00D 262 3577 002 FLI2310-LF-CF

IC702 00D 262 3303 001 K4S643232H-UC60 +REF

IC703 00D 262 3752 005 XC2C128-7TQG144C-VSW1

IC704 00D 262 3364 011 SII9030CTU-7

IC706 00D 263 1296 906 TA48025BF(T6L1,NQ)

IC707 00D 263 1282 907 BD7820FP-E2

IC708 00D 263 1295 907 TA48018BF(T6L1,NQ)

IC801 00D 262 3478 004 ADV7320
