PARTS LIST OF DVD MECHANISM UNIT
＊本表に"nsp" と記載されている部品は供給できません。
＊ Parts for which "nsp" is indicated on this table cannot be supplied.
＊本表に記載されている部品は、補修用部品のため製品に使用している部品とは一部、形状、寸法などが異なる場合があります。
＊ The parts listed below are for maintenance only, might differ from the parts used in the unit in appearances or dimensions.
Ref. No. Part No. Part Name Remarks Q'ty New
1 nsp MAIN CHASSIS ASS'Y 1
3 00D 9KA 2A73 8 GUIDE CLAMP ASS'Y 1
4 00D 9KC 2A00 3 LOADING MOTOR ASS'Y 1
5 00D 9KC 2G02 9 LOADING GEAR 1
6 00D 9KB 9G03 0 LOADING GEAR 2ND 1
7 00D 9KB 9G03 1 LOADING GEAR 3RD 1
8 nsp SUB CHASSIS-L 1
9 nsp SUB CHASSIS-R 1
10 00D 9KA 2A73 7 TRAY ASS'Y 1
11 00D 9KC 1G00 3 SLIDE-CAM 1
12 00D 9KC 1G00 4 TRAVERSE ARM 1
16 00D 9KB 9G01 5 LOADING BELT 1
17 nsp SWITCH P.W.B. 1
18 nsp 5P PH WIRE 1
19 00D 9KS 01W2 04 SWITCH ESE22MH21 1
20 00D 9KS 01W2 05 SWITCH ESE22MH23 1
21 nsp POLY.SLIT WASHER 2.6X6X0.25C 3
22 00D 445 8004 007 WIRE CLAMPER 1
23 nsp PRECISION SCREW 1.7X2.2 TYPE3 2
24 nsp SCREW 2.6X6 CBTS(B)-Z 6
25 nsp PRECISION SCREW 2X3(S) TYPE3 1
26 nsp SCREW 2X6 CBTS(P)-Z 2
27A 00D 9KA 2A69 3 TRAVERSE MECHA (FEED) ASS'Y Assembled part 1
23 - PRECISION SCREW 1.7X2.2 TYPE3 5
27 - PU CHASSIS ASS'Y 1
28 - SHAFT HOLDER L 1
29 - SHAFT HOLDER R 1
30 - SHAFT TILT BASE-W 1
31 - SHAFT TILT PLATE-W 1
32 - TILT SPRING 2
33 - MAIN SHAFT 1
34 - SUB SHAFT 1
35 - PU RACK GEAR 1
36 - FEED GEAR 2ND ASS'Y 1
37 - PICK UP SF-HD65G 1
39 - SHAFT SPRING 1
40 - RACK GEAR SPRING 1
41 - FEED MOTOR ASS'Y 1
42 - T/T MOTOR ASS'Y 1
43 - SCREW 2.6X6 CBTS(S)-Z 2
44 - SCREW 2.6X4 CBTS(S)-Z 1
46 - SCREW 2.6X15 CFTS(S)-Z 2
47 - SCREW 3X4 BSS 2
48 - SCREW 3X8 BSS (A) 1
50 - POLY.SLIT WASHER 2.1X4X0.25C 2
53 - FEED GEAR 3RD 1
49 00D 9KA 2G64 3 DAMPER 4
51 00D 9KC 1H01 2 SPECIAL SCREW 4
54 nsp TRAY-SPRING-VXF 1
56 nsp RUBBER CUSHION 2
59 nsp TRAY-CUSHION 1
66 00D 009 0276 006 24P FFC(0.5) 1
70 nsp TAPE W10X45 (NITTO NO.156) 1
