User Manual
61
/
76
1) Check the probe to assure its proper connection to the channel BNC;
2) Check the probe to assure its good connection to the measured object;
3) Check the probe to verify it has been well calibrated. Otherwise, refer to the content about calibration described in this
manual.
4. If the waveform is rolling continuously on the screen but can not be triggered, follow these steps:
1) Check the trigger source to make sure it consistent with the input channel;
2) Check the trigger level to assure its correct adjustment. You may push the TRIGGER LEVEL knob to reset the trigger
level back to the center of the signal;
3) Check the trigger mode to confirm it is a right choice for the input signal. The default trigger mode is edge trigger.
However, it is not suitable for all kinds of input signals.
6. Open Source Information
General Information:
FPGA Driver, I2C Driver,SPI Driver, IO-bank Driver, USB Host
Driver, LCD Driver, USB massstorage、gadget Driver
busybox1.18.4, gnupg1.4.11
License: GPLV2 See Appendix D
7. General Care and Cleaning
General Care
Do not put or leave the device in a place where the LCD display will be exposed to direct sunlight for long periods of time.
Note: To avoid damage to the oscilloscope or probes, do not expose them to sprays, liquids, or solvents.
Cleaning
Examine the oscilloscope and probes as often as operating conditions require. To clean the exterior surface, perform the
following steps:
To Next Page
