RP360 / RP360 XP
Expression Pedal
E
X
P
Selecting the Expression Pedal icon accesses settings to assign a parameter for expression pedal
control and set the minimum (toe up) and maximum (toe down) control limit values� See Expression
Pedal Control on page 34 for further information on configuring and using the Expression Pedal
built into the RP360XP or an external expression/volume pedal connected to the RP360�
Parameters
NAME OPTIONS OR RANGE DESCRIPTION
PARAMETER
SELECT
Varies Selects the desired parameter for control�
MIN Varies
Sets the minimum capable value when the expression pedal is in its toe up
position�
MAX Varies
Sets the maximum capable value when the expression pedal is in its toe down
position�
LFO
Selecting the LFO icon accesses settings to assign a parameter for LFO control� You can also set the
minimum and maximum range control limits, adjust the speed, and select the waveform type� See
Assigning The LFO on page 36 for further information on configuring and using the LFO for
modulating effect parameters�
Parameters
NAME OPTIONS OR RANGE DESCRIPTION
PARAMETER
CONTROLLED
Varies based on selection Selects the parameter you want the LFO to control�
MIN Varies based on selection
Adjusts the minimum value the LFO will set the parameter to
when it reaches the lower limit of its waveform�
MAX Varies based on selection
Adjusts the maximum value the LFO will set the parameter to
when it reaches the upper limit of its waveform�
SPEED 0�05 HZ - 10�00 HZ
Adjusts the rate at which the LFO will modulate the assigned
parameter�
WAVEFRM
TRIANGLE, SINE,
SQUARE
Selects the shape of the LFO waveform which changes the
timing characteristics of the LFO modulation�
