Page 23
Chapter 2
Receiver Description and Installation
Receiver Front Panel
Smart Card Door
Behind this door is a slot for a future smart card. No smart card is included with
this receiver.
Arrow Buttons
Use the ARROW buttons to change satellite channels displayed on the nearby
TV.
Indicators
• TV1 Power—The green light indicates that the receiver is providing
programming to the nearby TV through the
TV1 output connections.
•
TV2 Power—The blue light indicates that the receiver is providing
programming to the remote TVs through the
TV2 output connections.
•
Recording—Indicates that the receiver is recording. TV1 and TV2 each
have recording indicators.
•
Mode—Indicates if the receiver is in Single or Dual mode (see page 47 for
details).
Buttons
The buttons on the receiver give you some control of the receiver. However,
most of the time you will want to use the remote controls that came with your
receiver.
•
Mode—Press the receiver MODE button to switch between Single and
Dual mode (see page 47 for details).
Note: The first time you turn on your receiver, the receiver will be in Dual
mode. Press the MODE button to see if
Single Mode is available on your
receiver.
•
System Info—Displays the System Info screen on the nearby TV.
•
Menu—Displays the Main Menu. After you press this button, use the
ARROWS and SELECT buttons to navigate through
TV1’s menus.
