1-11
11C-M12M0-0004-0
2. MAINTENANCE
Clean the following parts
Rubber roller
Resin roller
Flat belt
Folding roller
Index plate
Photointerrupter
Main unit
Remote unit
Switching power supply
Oil the following parts (Equivalent to Nisseki Mitsubishi Co. Ld. FBK oil R028)
Sintering bearing
Link rotating fulcrum of the solenoid
Grease the following parts (Equivalent to Dowconning Co. Ld. MOLY KOTE X5-6020)
Stapler head
Where the flat cogwheels are engaged
Where the worm gears are engaged
Clincher mechanism sliding part
Folding knife sliding part
Folding roller sliding part
Resin idler (Apply to center pin)
Grease the following parts (Equivalent to Kyodoyushi Co. Ld. uniloob No.2)
Chain
Grease the following parts (Equivalent to Orelube G90-140 oil)
Driving plate (Apply a thin layer only to the part sliding over the clincher)
