1-10. Stopper Unit Motor
DC +24 V power supply stepping motor. Moves the stopper unit incorporating the stapling/folding stoppers.
1-11. Stopper Motor
DC +24 V power supply stepping motor. Drives the stapling/folding stoppers.
1-12. Stopper Home Sensor
Sensor for detecting the home positions of the stapling/folding stoppers. Uses a photointerrupter.
1-13. Stopper Paper Switch
Normal closed switch. Used for detecting paper tip and jams caused by paper remaining in the machine.
1-14. Side Jogger Motor
DC +24 V power supply stepping motor. Motor for driving the side jogger.
1-15. Back Jogger Motor
DC +24 V power supply stepping motor. Motor for driving the back jogger.
1-16. Back Jogger Home Sensor
Sensor for detecting the home position of the back jogger. Uses a photointerrupter.
1-17. Back Jogger Paper Sensor
Sensor for detecting paper tip and jams caused by paper remaining in the machine. Uses a photointerrupter.
1-18. Side-stapling Paper Ejection Solenoid
Solenoid for driving the rollers at the top of the stapling/folding stopper section. Uses a DC +24 V power.
1-19. Stacker Connection Connector
When the trimmer is not connected, connects the stacker unit.
1-20. Stacker Motor
Motor for driving the belt of the stacker unit. Uses a DC +24 V power.
1-21. Side-stapling Gate Solenoid
Solenoid for driving the stoppers for side-stapling and corner-stapling. Uses a DC +24 V power.
