Duplo DBM-120 Service Manual

2-24 11C-M12M0-0004-0
Maintenance Menu (Initial screen)
Select M. Mode
ROM Version
MC ROM Version
xxx-nnnnn
SPM ROM Version
xxx-nnnnn
OP ROM Version
xxx-nnnnn
IF ROM Version
xxx-nnnnn
Select M. Mode
Simulation Mode
Simulation
P. Less Running
Select M. Mode
Sensor Check
Sensor Check
B. Jogger PSW on
Sensor Check
Staple PSW on
Sensor Check
Stopper PSW on
Sensor Check
Top Out PSW on
Sensor Check
Bottom Out PSW on
Sensor Check
Stapler R Emp on
Sensor Check
Stapler L Emp on
Sensor Check
S. Jogger Hm on
Sensor Check
B. Jogger Hm on
Sensor Check
B.J. Unit Hm on
Sensor Check
Stp. Unit Hm on
6-2. LCD Map (Maintenance Mode)
NOTE : In the sensor check mode, the sensor state will be displayed as “on” or “off”.
