1-43. Main Power Switch
Incorporated in the remote unit. Used to turn ON/OFF the power supply of the machine.
1-44. Power Supply Inlet
Incorporated in the remote unit. Connected to the power cord.
1-45. Module Connector 1
Connector for communication with the machine connected. When performing communication from the upstream
processing unit, insert an interface cable.
1-46. Module Connector 2
Connector for communication with the machine connected. When performing communication to the downstream
processing unit, insert an interface cable.
1-47. LED 1 (Green)
Lights up in green when power is supplied to the machine.
1-48. LED 2 (Orange)
Lights up only when the remote function is effective and the power is supplied from the upstream processing unit.
1-49. IF Cable
Interface cable for communication with the downstream processing unit.
1-50. Power Cord
Supplies primary power to the machine.
