Duplo DBM-120 Service Manual

2-2 11C-M12M0-0004-0
1. BLOCK DIAGRAM OF STRUCTURE AND OUTLINE OF EACH BLOCK
1-3. Staple motor
1-21. Side-stapling gate solenoid
1-2. OP unit
(Control panel)
1-1. MC unit
1-4. Knife motor
1-5. Folding conveyance motor
1-6. Conveyance motor
1-7. Cover switch
1-8. Movable table motor
1-9. Back jogger unit motor
1-10. Stopper unit motor
1-11. Stopper motor
1-12. Stopper home sensor
1-13. Stopper paper switch
1-14. Side jogger motor
1-15. Back jogger motor
1-16. Back jogger home sensor
1-17. Back jogger paper sensor
1-18. Side-stapling paper ejection solenoid
1-19. Stacker connection connector
1-22. Conveyance clutch
1-23. Total counter
1-24. Staple home sensor
1-25. Movable table home sensor
1-26. Knife home sensor
1-27. Staple index sensor
1-28. Knife index sensor
1-29. Folding conveyance index sensor
1-30. Conveyance index sensor
1-31. Option sensor
1-32. Back unit home sensor
1-33. Stopper unit home sensor
1-34. Side jogger home sensor
1-35. Staple paper switch
1-36. Saddle-stapling paper ejection paper switch
1-37 . Side-stapling paper ejection paper switch
1-38. No-staple R sensor
1-39. No-staple L sensor
1-20. Stacker motor
1-40. Switching power supply
1-42. Power supply switch
1-45. Module connector 1
1-43. Main power switch
1-44. Power supply inlet
(When not connected to
the trimmer)
1-46. Module connector 2
1-47. LED 1
1-48. LED 2
1-41. Remote unit
(RM unit)
1-50. Power cord
1-49. IF cable
To trimmer
