4 Technical data
Electrical data 7805-100-50
7805-200-50
7805-200-60
Voltage V 230 230
Mains frequency Hz 50 60
Rated power W 210 260
Nominal current A 1.0 1.2
Fuses* (2x) T 4.0 AH
Type of protection IP 21
Protection class I
Over-voltage category II
* in accordance with IEC 60127-2
Electrical data – electronics
Switching performance signal output
Max. voltage
Max. nominal current
V
mA
24 AC/DC
120
Signal input from the hose manifold V 24 AC/DC
Media and connections
Fluid volume
min.
max.
l/min
l/min
0.1
16
Usable volume, disposable amalgam con-
tainer ccm approx. 600
Replacement interval Months 9 - 12
Dürr Connect inlet and outlet connection Hose, 20 mm (inside)
General data
Speed
rpm 2900 3470
Duty cycle % 95 (S 5 min)
Dimensions (H x W x D) cm 41 x 25 x 32
Weight kg 10
Noise level*
without housing; approx.
with housing; approx.
dB(A)
dB(A)
57
47
65
56
Separation rate **
%
³ 95 ³ 95
* Noise level in accordance with EN ISO 3746
** in accordance with ISO 11143
Network connection
LAN technology Ethernet
Product description
8 9000-606-44/30 2011V003
EN
